Jean Berthier

Open microfluidics, the study of microflows having a boundary with surrounding air, encompasses different aspects such as paper or thread-based microfluidics, droplet microfluidics and open-channel microfluidics.Open-channel microflow is a flow at the micro-scale, guided by solid structures, and having at least a free boundary (with air or vapor) other than the advancing meniscus. This book is devoted to the study of open-channel microfluidics which (contrary to paper or thread or droplet microfluidics) is still very sparsely documented, but bears many new applications in biology, biotechnology, medicine, material and space sciences. Capillarity being the principal force triggering an open microflow, the principles of capillarity are first recalled. The onset of open-channel microflow is next analyzed and the fundamental notion of generalized Cassie angle (the apparent contact angle which accounts for the presence of air) is presented. The theory of the dynamics of open-channel microflows is then developed, using the notion of averaged friction length which accounts for the presence of air along the boundaries of the flow domain. Different channel morphologies are studied and geometrical features such as valves and capillary pumps are examined. An introduction to two-phase open-channel microflows is also presented showing that immiscible plugs can be transported by an open-channel flow. Finally, a selection of interesting applications in the domains of space, materials, medicine and biology is presented, showing the potentialities of open-channel microfluidics.

Open microfluidics, the study of microflows having a boundary with surrounding air, encompasses different aspects such as paper or thread-based microfluidics, droplet microfluidics and open-channel microfluidics.Open-channel microflow is a flow at the micro-scale, guided by solid structures, and having at least a free boundary (with air or vapor) other than the advancing meniscus. This book is devoted to the study of open-channel microfluidics which (contrary to paper or thread or droplet microfluidics) is still very sparsely documented, but bears many new applications in biology, biotechnology, medicine, material and space sciences. Capillarity being the principal force triggering an open microflow, the principles of capillarity are first recalled. The onset of open-channel microflow is next analyzed and the fundamental notion of generalized Cassie angle (the apparent contact angle which accounts for the presence of air) is presented. The theory of the dynamics of open-channel microflows is then developed, using the notion of averaged friction length which accounts for the presence of air along the boundaries of the flow domain. Different channel morphologies are studied and geometrical features such as valves and capillary pumps are examined. An introduction to two-phase open-channel microflows is also presented showing that immiscible plugs can be transported by an open-channel flow. Finally, a selection of interesting applications in the domains of space, materials, medicine and biology is presented, showing the potentialities of open-channel microfluidics.

Open microfluidics or open-surface is becoming fundamental in scientific domains such as biotechnology, biology and space. First, such systems and devices based on open microfluidics make use of capillary forces to move fluids, without any need for external energy. Second, the "openness" of the flow facilitates the accessibility to the liquid in biotechnology and biology, and reduces the weight in space applications. This book has been conceived to give the reader the fundamental basis of open microfluidics. It covers successively The theory of spontaneous capillary flow, with the general conditions for spontaneous capillary flow, and the dynamic aspects of such flows.The formation of capillary filaments which are associated to small contact angles and sharp grooves.The study of capillary flow in open rectangular, pseudo-rectangular and trapezoidal open microchannels.The dynamics of open capillary flows in grooves with a focus on capillary resistors. The case of very viscous liquids is analyzed.An analysis of suspended capillary flows: such flows move in suspended channels devoid of top cover and bottom plate. Their accessibility is reinforced, and such systems are becoming fundamental in biology.An analysis of “rails” microfluidics, which are flows that move in channels devoid of side walls. This geometry has the advantage to be compatible with capillary networks, which are now of great interest in biotechnology, for molecular detection for example.Paper-based microfluidics where liquids wick flat paper matrix. Applications concern bioassays such as point of care devices (POC).Thread-based microfluidics is a new domain of investigation. It is seeing presently many new developments in the domain of separation and filtration, and opens the way to smart bandages and tissue engineering. The book is intended to cover the theoretical aspects of open microfluidics, experimental approaches, and examples of application.

In this 2nd edition of Micro-Drops and Digital Microfluidics, Jean Berthier explores the fundamentals and applications of digital microfluidics, enabling engineers and scientists to design this important enabling technology into devices and harness the considerable potential of digital microfluidics in testing and data collection. This book describes the most recent developments in digital microfluidics, with a specific focus on the computational, theoretical and experimental study of microdrops. Unique in its emphasis on digital microfluidics and with diverse applications ranging from drug delivery to point-of-care diagnostic chips, organic synthesis to microreactors, Micro-Drops and Digital Microfluidics meets the needs of audiences across the fields of bioengineering and biotechnology, and electrical and chemical engineering.

The Physics of Microdroplets gives the reader the theoretical and numerical tools to understand, explain, calculate, and predict the often nonintuitive observed behavior of droplets in microsystems. Microdrops and interfaces are now a common feature in most fluidic microsystems, from biology, to biotechnology, materials science, 3D-microelectronics, optofluidics, and mechatronics. On the other hand, the behavior of droplets and interfaces in today's microsystems is complicated and involves complex 3D geometrical considerations. From a numerical standpoint, the treatment of interfaces separating different immiscible phases is difficult. After a chapter dedicated to the general theory of wetting, this practical book successively details: The theory of 3D liquid interfaces The formulas for volume and surface of sessile and pancake dropletsThe behavior of sessile dropletsThe behavior of droplets between tapered plates and in wedges The behavior of droplets in microchannels The effect of capillarity with the analysis of capillary rise The onset of spontaneous capillary flow in open microfluidic systems The interaction between droplets, like engulfment The theory and application of electrowetting The state of the art for the approach of 3D-microelectronics using capillary alignment

The application of microfluidics to biotechnology is an exciting new area that has already begun to revolutionize how researchers study and manipulate macromolecules like DNA, proteins and cells in vitro and within living organisms. Now in a newly revised and expanded second edition, the Artech House bestseller, "Microfluidics for Biotechnology" brings professionals and students to the cutting edge of this burgeoning field. Featuring numerous updates and including three entirely new chapters, this book provides a detailed look at the mechanical behavior of the different types of micro/nano particles and macromolecules that are used in biotechnology. Engineers and laboratory researchers involved with the conception and design of bio-tech microdevices, as well as graduate and post-graduate students in related courses.
