Udit Mamodiya

Injection Moulding Machine has more temperature trouble shooting problem, this problem could be attempted by PID controller tuning process and presented in this report. The aim was to provide solutions to improve the general behaviour of a control system, with Proportional Integral Derivative (PID) controller structure. The report contains the simulation results of proposed controllers and their comparison with contemporary work. It includes problem statement and objectives as performance analysis of P, PD, PI and PID controllers for Injection Moulding Machine. The report includes experimental analysis four types of controller's analysis finalization of temperature controller parameters through variation and selection best performances.
